Select VLANs: 30T, 50T, 55T and using the right arrow move them into the box on the right side.To join and tag VLANs on the GE1 interface perform the following steps shown in Figure-6: Figure-6 Using interface eth01 on the EdgeRouter and connecting it to interface GE1 on the SG-300-20. In order for the EdgeRouter to provide DHCP to multiple VLANs, all necessary VLANs need to be tagged on the Cisco SG300-20 switch and sub-interfaces created for each VLAN on the EdgeRouter, see Table-1. Voila, firmware upgraded from v1.2.0 to 1.9.0, as shown on Figure-5, now too configuring the VLANs. Next up is to configure trunking on the SG-300-20. Once the update completes you will be presented with Upgrade complete dialog box.

Ok, now that the firmware is downloaded time to upgrade the EdgeRouter as shown in Figure-4. Figure-1 Figure-2įrom the download page, select the correct device as seen in Figure-3: Figure-3 Luckily Ubiquiti makes upgrading the firmware a breeze by providing the download link to the firmware from within the user interface, Figure-2. Upon receiving the device I noticed the firmware version was v1.2.0, Figure-1.

Relocate DHCP server from Synology NAS to EdgeRouter.

Creating VLANs and Sub-Interfaces on the EdgeRouter.

I decided to make some design changes with regards to the networking but before discussing those I need to first update the firmware. For me the routing and POE capabilities was the selling point as I’ve been wanting to play with OSPF and NSX in the homelab for some time now and being able to power security cameras from the router is super convenient. I wanted to have the ability to mount this in my rack so I also splurged on a mount from ebay. The EdgeRouter is feature packed at a reasonable price point and perfect for most homelabbers.

I decided to pull the trigger and order the ERPOE-5 to replace my aging pfSense box. After hearing good things about the Ubiquiti EdgeRouter.
